基本描述

别名	萘-1,4,5,8-四甲酸二酐
英文别名	NTCDA \| AKOS003614689 \| 1,8:4, 5-Naphthalenetetracarboxylic dianhydride \| Isochromeno[6,5,4-def]isochromene-1,3,6,8-tetraone \| N0755 \| Naphthalene-1,8:4,5-tetracarboxylic dianhydride \| NCGC00357221-01 \| NSC 84241 \| 1,4,5,8-naphthalenetetracarboxylic-1,8:4
规格或纯度	≥96%
英文名称	1,4,5,8-Naphthalenetetracarboxylic dianhydride
储存温度	充氩
运输条件	常规运输
产品介绍	一种n-channel organic semiconductor，用于合成耐高温高分子材料的单体,用于染料,颜料的中间体 1,4,5,8-Naphthalenetetracarboxylic dianhydride (NTCDA) is a tetrafunctional monomer that can be used as an electron transporting material in organic electronics

AI解读

名称和识别符

PubChem SID	504751153
EC号	201-342-5
IUPAC Name	6,13-dioxatetracyclo[6.6.2.04,16.011,15]hexadeca-1(15),2,4(16),8,10-pentaene-5,7,12,14-tetrone
INCHI	InChI=1S/C14H4O6/c15-11-5-1-2-6-10-8(14(18)20-12(6)16)4-3-7(9(5)10)13(17)19-11/h1-4H
InChi Key	YTVNOVQHSGMMOV-UHFFFAOYSA-N
Canonical SMILES	C1=CC2=C3C(=CC=C4C3=C1C(=O)OC4=O)C(=O)OC2=O
Isomeric SMILES	C1=CC2=C3C(=CC=C4C3=C1C(=O)OC4=O)C(=O)OC2=O
WGK Germany	2
RTECS	QK3695000
PubChem CID	6678
分子量	268.18
Beilstein号	272788
Reaxy-Rn	272788

化学和物理性质

密度	1.6218
敏感性	对湿度敏感
熔点	>300℃
分子量	268.180 g/mol
XLogP3	1.900
氢键供体数Hydrogen Bond Donor Count	0
氢键受体数Hydrogen Bond Acceptor Count	6
可旋转键计数Rotatable Bond Count	0
精确质量Exact Mass	268.001 Da
单同位素质量Monoisotopic Mass	268.001 Da
拓扑极表面积Topological Polar Surface Area	86.700 Å²
重原子数Heavy Atom Count	20
形式电荷Formal Charge	0
复杂度Complexity	446.000
同位素原子数Isotope Atom Count	0
定义的原子立体中心计数Defined Atom Stereocenter Count	0
未定义的原子立体中心计数Undefined Atom Stereocenter Count	0
定义的键立体中心计数Defined Bond Stereocenter Count	0
未定义的键立体中心计数Undefined Bond Stereocenter Count	0
所有立体化学键的总数The total count of all stereochemical bonds	0
共价键合单元计数Covalently-Bonded Unit Count	1

安全和危险性（GHS）

象形图	GHS07
信号词	Warning
危险声明	H315: 引起皮肤刺激 H319: 引起严重眼睛刺激 H335: 可能引起呼吸道刺激
预防措施声明	P261: 避免吸入灰尘/烟雾/气体/雾/蒸汽/喷雾 P305+P351+P338: 如进入眼睛：用水小心冲洗几分钟。如戴隐形眼镜并可方便地取出，取出隐形眼镜。继续冲洗。 P280: 戴防护手套/穿防护服/戴防护眼罩/戴防护面具。 P302+P352: 如皮肤沾染：用水充分清洗。 P321: 特殊处理（请参阅此标签上的...）。 P405: 密闭存放 P501: 将内容物/容器处理到。。。 P264: 处理后要彻底洗手。 P271: 仅在室外或通风良好的地方使用。 P304+P340: 如误吸入：将人转移到空气新鲜处，保持呼吸舒适体位。 P403+P233: 存放在通风良好的地方。保持容器密闭。 P362+P364: 脱掉沾污的衣服，清洗后方可重新使用。 P264+P265: 处理后彻底洗手[和…]。不要触摸眼睛。 P337+P317: 如果眼睛刺激持续：寻求医疗帮助。 P332+P317: 如果出现皮肤刺激：请寻求医疗帮助。 P319: 如果你感到不适，请寻求医疗帮助。
WGK Germany	2
RTECS	QK3695000
Reaxy-Rn	272788
个人防护装备	dust mask type N95 (US),Eyeshields,Gloves

技术规格说明书

Purity(HPLC)	96-100（%）
Appearance（N107577)	White to Yellow to Brown Powder,Crystals or Solid
Infrared spectrum	Conforms to Structure
Proton NMR spectrum	Conforms to Structure

技术规格说明书

质检证书（CoA,COO,BSE/TSE 和分析图谱)

C of A & Other Certificates(BSE/TSE, COO):

输入批号以搜索分析图谱:

通过匹配包装上的批号来查找并下载产品的 COA，每批产品都进行了严格的验证，您可放心使用！

找到46个结果

批号(Lot Number)	证书类型	日期	货号
E2512428	分析证书	25-05-17	N107577
E2512427	分析证书	25-05-17	N107577
E2512426	分析证书	25-05-17	N107577
E2512425	分析证书	25-05-17	N107577
E2512424	分析证书	25-05-17	N107577
L2417667	分析证书	24-12-24	N107577
L2417663	分析证书	24-12-24	N107577
C2521258	分析证书	24-12-24	N107577
L2417664	分析证书	24-12-24	N107577
L2417665	分析证书	24-12-24	N107577
L2417666	分析证书	24-12-24	N107577
G2418533	分析证书	24-07-22	N107577
G2418528	分析证书	24-07-22	N107577
G2418526	分析证书	24-07-22	N107577
G2418534	分析证书	24-07-22	N107577
C2406155	分析证书	24-03-29	N107577
G2412022	分析证书	24-03-29	N107577
J2423265	分析证书	24-03-29	N107577
C2406154	分析证书	24-03-29	N107577
C2406507	分析证书	24-03-29	N107577
K2310479	分析证书	23-11-15	N107577
K2310478	分析证书	23-11-15	N107577
K2310480	分析证书	23-11-15	N107577
K2310481	分析证书	23-11-15	N107577
A2403091	分析证书	23-11-14	N107577
K2310482	分析证书	23-11-14	N107577
J2313102	分析证书	23-07-29	N107577
G2319709	分析证书	23-07-29	N107577
G2319712	分析证书	23-07-29	N107577
G2319715	分析证书	23-07-29	N107577
G2319708	分析证书	23-07-29	N107577
G2319707	分析证书	23-07-29	N107577
F23062139	分析证书	23-06-20	N107577
F23061294	分析证书	23-06-20	N107577
F23061250	分析证书	23-06-20	N107577
F23061317	分析证书	23-06-20	N107577
D23211588	分析证书	23-04-27	N107577
D23211431	分析证书	23-04-27	N107577
D23211418	分析证书	23-04-27	N107577
D23211424	分析证书	23-04-27	N107577
I2227133	分析证书	22-10-11	N107577
B2212389	分析证书	22-09-01	N107577
B2212359	分析证书	22-09-01	N107577
B2212353	分析证书	22-09-01	N107577
B2212352	分析证书	22-09-01	N107577
H2229673	分析证书	22-09-01	N107577

显示更多⌵

此产品的引用文献

如何在您的发表作品中引用阿拉丁的产品和网站?

1. Lingchang Jiang,Pengyuan Wang,Meiping Li,Panpan Zhang,Jialu Li,Jia Liu,Yanhang Ma,Hao Ren,Guangshan Zhu. (2019-04-25) Construction of a Stable Crystalline Polyimide Porous Organic Framework for C2 H2 /C2 H4 and CO2 /N2 Separation.. Chemistry (Weinheim an der Bergstrasse, Germany), 25 ((38)): (9045-9051). [PMID:31016784]
2. Linhong Liao, Xiao Lin, Jie Zhang, Zhiyuan Hu, Fengshou Wu. (2023) Facile preparation of carbon dots with multicolor emission for fluorescence detection of ascorbic acid, glutathione and moisture content. JOURNAL OF LUMINESCENCE, 264 (17): (120169). [PMID:11054574] [10.1016/j.jlumin.2023.120169]
3. Yanqing Cong, Xinyue Li, Shiyi Zhang, Qiuang Zheng, Yi Zhang, Shi-Wen Lv. (2023) Embedding Carbon Quantum Dots into Crystalline Polyimide Covalent Organic Frameworks to Enhance Water Oxidation for Achieving Dual-Channel Photocatalytic H2O2 Generation in a Wide pH Range. ACS Applied Materials & Interfaces, 15 (37): (43799–43809). [PMID:37672480] [10.1021/acsami.3c09039]
4. Liao Linhong, Lin Xiao, Wang Kai, Hu Zhiyuan, Wu Fengshou. (2023) Highly luminescent nitrogen and sulfur co-doped carbon dots for Sn2+ and S2− sensing and dual-mode anti-counterfeiting. MICROCHIMICA ACTA, 190 (8): (1-11). [PMID:37507622] [10.1007/s00604-023-05922-9]
5. Hui Ling, Ziting Zhen, Yuhang Sun, Gang Li, Chao Wang, Xiaoping Yang. (2023) Enhancement of interfacial properties of HMCF composites by constructing of rigid-flexible interphase through naphthalenediimide with different flexible chain lengths. POLYMER COMPOSITES, 44 (9): (6149-6163). [10.1002/pc.27553]
6. Meichen Guo, Wu Tang, Chenbin Tang, Xuesong He, Jiahui Hu, Cong Fan. (2023) Small-Molecule Organic Cathodes with Carbon Coating for Highly Efficient Potassium-ion Batteries. ChemSusChem, 16 (15): (e202300343). [PMID:37013264] [10.1002/cssc.202300343]
7. Le Cheng, Tinghao Ma, Binghao Zhang, Libei Huang, Weihua Guo, Feijun Hu, He Zhu, Zhaoyu Wang, Tingting Zheng, Deng-Tao Yang, Chi-Kit Siu, Qi Liu, Yang Ren, Chuan Xia, Ben Zhong Tang, Ruquan Ye. (2022) Steering the Topological Defects in Amorphous Laser-Induced Graphene for Direct Nitrate-to-Ammonia Electroreduction. ACS Catalysis, 12 (19): (11639–11650). [10.1021/acscatal.2c03219]
8. Gao Jingqing, Liu Xiaobang, Ren Peng, Gao Jianlei, Chen Yong, Chen Zhijun. (2022) Removal behavior and mechanism of amino/carboxylate-functionalized Fe@SiO2 for Cr(VI) and Cd(II) from aqueous solutions. ENVIRONMENTAL SCIENCE AND POLLUTION RESEARCH, 29 (47): (72058-72073). [PMID:35610446] [10.1007/s11356-022-20048-w]
9. Di Liu, Yunning Chen, Renquan Guan, Jie Zhao, Huimin Jin, Siyi Zhang, Qingkun Shang. (2022) Photocatalytic performance of heterojunction S-Tyr-NDI-Tyr/TiO2 formed by self-assembled naphthalimide derivatives and titanium dioxide. CHEMOSPHERE, 296 (134046). [PMID:35183575] [10.1016/j.chemosphere.2022.134046]
10. Wei Li, Yanhong Li, Jürgen Caro, Aisheng Huang. (2022) Fabrication of a flexible hydrogen-bonded organic framework based mixed matrix membrane for hydrogen separation. JOURNAL OF MEMBRANE SCIENCE, 643 (120021). [10.1016/j.memsci.2021.120021]
11. Minhui Zheng, Zhoulu Wang, Qiang Ru, Haikuo Fu, Jun Zhang, Zikang Pan, Jiaqi Wang, Qizhen Xie, Xing Zhao. (2022) NASICON type KTi2(PO4)3 decorated by NTCDA-derived carbon layer for enhanced lithium/sodium storage. JOURNAL OF COLLOID AND INTERFACE SCIENCE, 606 (1906). [PMID:34689047] [10.1016/j.jcis.2021.10.009]
12. Lihong Tao, Jianjun Zhao, Jun Chen, Caixia Ou, Weixia Lv, Shengwen Zhong. (2021) 1,4,5,8-Naphthalenetetracarboxylic dianhydride grafted phthalocyanine macromolecules as an anode material for lithium ion batteries. Nanoscale Advances, 3 (11): (3199-3215). [PMID:36133650] [10.1039/D1NA00115A]
13. Liu Xufei, Qiu Shengqiang, Mei Peng, Zhang Qing, Yang Yingkui. (2021) Chain structure-dependent electrochemical performance of polyimide cathode materials for lithium-ion batteries. JOURNAL OF MATERIALS SCIENCE, 56 (5): (3900-3910). [10.1007/s10853-020-05510-9]
14. Kai Hu, Jingyi Qiao, Weixia Zhu, Xiaohui Chen, Chunhong Dong. (2019) Magnetic naphthalene-based polyimide polymer for extraction of Sudan dyes in chili sauce. MICROCHEMICAL JOURNAL, 149 (104073). [10.1016/j.microc.2019.104073]
15. Kaixiang Shi, Hongyan Yao, Yongcun Zou, Yanfeng Wei, Ningning Song, Shuai Zhang, Ye Tian, Shiyang Zhu, Bo Zhang, Shaowei Guan. (2019) Crosslinked porphyrin-based polyimides: Tunable porosity parameters and carbon dioxide adsorption. MICROPOROUS AND MESOPOROUS MATERIALS, 287 (246). [10.1016/j.micromeso.2019.06.016]
16. Ying Zhang, Ronglan Zhang, Fei Yang, Jianshe Zhao. (2018) Binuclear Metal Phthalocyanines Catalysis for Li/SOCl2 Batteries: An Experimental and Computational Study. Energy Technology, 6 (7): (1342-1351). [10.1002/ente.201700929]
17. Ting Wang, Rui Xue, Huiqin Chen, Peiling Shi, Xi Lei, Yuli Wei, Hao Guo, Wu Yang. (2017) Preparation of two new polyimide bond linked porous covalent organic frameworks and their fluorescence sensing application for sensitive and selective determination of Fe3+. NEW JOURNAL OF CHEMISTRY, 41 (23): (14272-14278). [10.1039/C7NJ02134H]
18. Lihua Ma, Song Guo, Jifu Sun, Caishun Zhang, Jianzhang Zhao, Huimin Guo. (2013) Green light-excitable naphthalenediimide acetylide-containing cyclometalated Ir(III) complex with long-lived triplet excited states as triplet photosensitizers for triplet–triplet annihilation upconversion. DALTON TRANSACTIONS, 42 (18): (6478-6488). [PMID:23471114] [10.1039/C3DT32815E]
19. Shaozhong Zeng, Limin Guo, Fangming Cui, Zhe Gao, Jian Zhou, Jianlin Shi. (2010) In situ Self-Assembly of Zigzag Polyimide Chains to Crystalline Branched Supramolecular Structures with High Surface Area. MACROMOLECULAR CHEMISTRY AND PHYSICS, 211 (6): (698-705). [10.1002/macp.200900506]

参考文献

1. Deepak Asthana,M R Ajayakumar,Rajendra Prasad Pant,Pritam Mukhopadhyay. (2012-04-28) NTCDA-TTF first axial fusion: emergent panchromatic, NIR optical, multi-state redox and high optical contrast photooxidation.. Chemical communications (Cambridge, England), 48 ((52)): (6475-6477). [PMID:22540127]
2. Subashani Maniam,Rosalind P Cox,Steven J Langford,Toby D M Bell. (2015-02-03) Unexpected photoluminescence of fluorinated naphthalene diimides.. Chemistry (Weinheim an der Bergstrasse, Germany), 21 ((10)): (4133-4140). [PMID:25639556]
3. Guangbao Wu,Zhi-Guo Zhang,Yongfang Li,Caiyan Gao,Xin Wang,Guangming Chen. (2017-05-17) Exploring High-Performance n-Type Thermoelectric Composites Using Amino-Substituted Rylene Dimides and Carbon Nanotubes.. ACS nano, 11 ((6)): (5746-5752). [PMID:28511002]
4. Lingchang Jiang,Pengyuan Wang,Meiping Li,Panpan Zhang,Jialu Li,Jia Liu,Yanhang Ma,Hao Ren,Guangshan Zhu. (2019-04-25) Construction of a Stable Crystalline Polyimide Porous Organic Framework for C2 H2 /C2 H4 and CO2 /N2 Separation.. Chemistry (Weinheim an der Bergstrasse, Germany), 25 ((38)): (9045-9051). [PMID:31016784]
5. Nerea Casado,Daniele Mantione,Devaraj Shanmukaraj,David Mecerreyes. (2019-10-24) Symmetric All-Organic Battery Containing a Dual Redox-Active Polymer as Cathode and Anode Material.. ChemSusChem, 13 ((9)): (2464-2470). [PMID:31643146]
6. Mohammad A Jafar Mazumder,Panchami H Raja,Arun M Isloor,Muhammad Usman,Shakhawat H Chowdhury,Shaikh A Ali,Inamuddin,Amir Al-Ahmed. (2020-04-29) Assessment of sulfonated homo and co-polyimides incorporated polysulfone ultrafiltration blend membranes for effective removal of heavy metals and proteins.. Scientific reports, 10 ((1)): (7049-7049). [PMID:32341422]
7. Bo Tang,Chenyu Sun,Wei Wang,Lina Geng,Liquan Sun,Aiqin Luo. (2020-07-06) Chiral amorphous metal-organic polyhedra used as the stationary phase for high-resolution gas chromatography separations.. Chirality, 32 ((9)): (1178-1185). [PMID:32623797]
8. Bing Sun,Xinle Li,Tiantian Feng,Songliang Cai,Teresa Chen,Chenhui Zhu,Jian Zhang,Dong Wang,Yi Liu. (2020-11-10) Resistive Switching Memory Performance of Two-Dimensional Polyimide Covalent Organic Framework Films.. ACS applied materials & interfaces, 12 ((46)): (51837-51845). [PMID:33161710]
9. Tankut Türel,Suresh Valiyaveettil. (2020-07-08) A Naphthalene Diimide Based Macrocycle Containing Quaternary Ammonium Groups: An Electron-Deficient Host for Aromatic Carboxylate Derivatives.. ChemPlusChem, 85 ((7)): (1430-1437). [PMID:32633091]
10. Bo Tang,Xin Zhang,Lina Geng,Liquan Sun,Aiqin Luo. (2020-12-20) A chiral metal-organic cage used as the stationary phase for gas chromatography separations.. Journal of chromatography. A, 1636 (461792-461792). [PMID:33340747]
11. Linhong Liao, Xiao Lin, Jie Zhang, Zhiyuan Hu, Fengshou Wu. (2023) Facile preparation of carbon dots with multicolor emission for fluorescence detection of ascorbic acid, glutathione and moisture content. JOURNAL OF LUMINESCENCE, 264 (17): (120169). [PMID:11054574] [10.1016/j.jlumin.2023.120169]
12. Yanqing Cong, Xinyue Li, Shiyi Zhang, Qiuang Zheng, Yi Zhang, Shi-Wen Lv. (2023) Embedding Carbon Quantum Dots into Crystalline Polyimide Covalent Organic Frameworks to Enhance Water Oxidation for Achieving Dual-Channel Photocatalytic H2O2 Generation in a Wide pH Range. ACS Applied Materials & Interfaces, 15 (37): (43799–43809). [PMID:37672480] [10.1021/acsami.3c09039]
13. Liao Linhong, Lin Xiao, Wang Kai, Hu Zhiyuan, Wu Fengshou. (2023) Highly luminescent nitrogen and sulfur co-doped carbon dots for Sn2+ and S2− sensing and dual-mode anti-counterfeiting. MICROCHIMICA ACTA, 190 (8): (1-11). [PMID:37507622] [10.1007/s00604-023-05922-9]
14. Hui Ling, Ziting Zhen, Yuhang Sun, Gang Li, Chao Wang, Xiaoping Yang. (2023) Enhancement of interfacial properties of HMCF composites by constructing of rigid-flexible interphase through naphthalenediimide with different flexible chain lengths. POLYMER COMPOSITES, 44 (9): (6149-6163). [10.1002/pc.27553]
15. Meichen Guo, Wu Tang, Chenbin Tang, Xuesong He, Jiahui Hu, Cong Fan. (2023) Small-Molecule Organic Cathodes with Carbon Coating for Highly Efficient Potassium-ion Batteries. ChemSusChem, 16 (15): (e202300343). [PMID:37013264] [10.1002/cssc.202300343]
16. Le Cheng, Tinghao Ma, Binghao Zhang, Libei Huang, Weihua Guo, Feijun Hu, He Zhu, Zhaoyu Wang, Tingting Zheng, Deng-Tao Yang, Chi-Kit Siu, Qi Liu, Yang Ren, Chuan Xia, Ben Zhong Tang, Ruquan Ye. (2022) Steering the Topological Defects in Amorphous Laser-Induced Graphene for Direct Nitrate-to-Ammonia Electroreduction. ACS Catalysis, 12 (19): (11639–11650). [10.1021/acscatal.2c03219]
17. Gao Jingqing, Liu Xiaobang, Ren Peng, Gao Jianlei, Chen Yong, Chen Zhijun. (2022) Removal behavior and mechanism of amino/carboxylate-functionalized Fe@SiO2 for Cr(VI) and Cd(II) from aqueous solutions. ENVIRONMENTAL SCIENCE AND POLLUTION RESEARCH, 29 (47): (72058-72073). [PMID:35610446] [10.1007/s11356-022-20048-w]
18. Di Liu, Yunning Chen, Renquan Guan, Jie Zhao, Huimin Jin, Siyi Zhang, Qingkun Shang. (2022) Photocatalytic performance of heterojunction S-Tyr-NDI-Tyr/TiO2 formed by self-assembled naphthalimide derivatives and titanium dioxide. CHEMOSPHERE, 296 (134046). [PMID:35183575] [10.1016/j.chemosphere.2022.134046]
19. Wei Li, Yanhong Li, Jürgen Caro, Aisheng Huang. (2022) Fabrication of a flexible hydrogen-bonded organic framework based mixed matrix membrane for hydrogen separation. JOURNAL OF MEMBRANE SCIENCE, 643 (120021). [10.1016/j.memsci.2021.120021]
20. Minhui Zheng, Zhoulu Wang, Qiang Ru, Haikuo Fu, Jun Zhang, Zikang Pan, Jiaqi Wang, Qizhen Xie, Xing Zhao. (2022) NASICON type KTi2(PO4)3 decorated by NTCDA-derived carbon layer for enhanced lithium/sodium storage. JOURNAL OF COLLOID AND INTERFACE SCIENCE, 606 (1906). [PMID:34689047] [10.1016/j.jcis.2021.10.009]
21. Lihong Tao, Jianjun Zhao, Jun Chen, Caixia Ou, Weixia Lv, Shengwen Zhong. (2021) 1,4,5,8-Naphthalenetetracarboxylic dianhydride grafted phthalocyanine macromolecules as an anode material for lithium ion batteries. Nanoscale Advances, 3 (11): (3199-3215). [PMID:36133650] [10.1039/D1NA00115A]
22. Liu Xufei, Qiu Shengqiang, Mei Peng, Zhang Qing, Yang Yingkui. (2021) Chain structure-dependent electrochemical performance of polyimide cathode materials for lithium-ion batteries. JOURNAL OF MATERIALS SCIENCE, 56 (5): (3900-3910). [10.1007/s10853-020-05510-9]
23. Kai Hu, Jingyi Qiao, Weixia Zhu, Xiaohui Chen, Chunhong Dong. (2019) Magnetic naphthalene-based polyimide polymer for extraction of Sudan dyes in chili sauce. MICROCHEMICAL JOURNAL, 149 (104073). [10.1016/j.microc.2019.104073]
24. Kaixiang Shi, Hongyan Yao, Yongcun Zou, Yanfeng Wei, Ningning Song, Shuai Zhang, Ye Tian, Shiyang Zhu, Bo Zhang, Shaowei Guan. (2019) Crosslinked porphyrin-based polyimides: Tunable porosity parameters and carbon dioxide adsorption. MICROPOROUS AND MESOPOROUS MATERIALS, 287 (246). [10.1016/j.micromeso.2019.06.016]
25. Ying Zhang, Ronglan Zhang, Fei Yang, Jianshe Zhao. (2018) Binuclear Metal Phthalocyanines Catalysis for Li/SOCl2 Batteries: An Experimental and Computational Study. Energy Technology, 6 (7): (1342-1351). [10.1002/ente.201700929]
26. Ting Wang, Rui Xue, Huiqin Chen, Peiling Shi, Xi Lei, Yuli Wei, Hao Guo, Wu Yang. (2017) Preparation of two new polyimide bond linked porous covalent organic frameworks and their fluorescence sensing application for sensitive and selective determination of Fe3+. NEW JOURNAL OF CHEMISTRY, 41 (23): (14272-14278). [10.1039/C7NJ02134H]
27. Lihua Ma, Song Guo, Jifu Sun, Caishun Zhang, Jianzhang Zhao, Huimin Guo. (2013) Green light-excitable naphthalenediimide acetylide-containing cyclometalated Ir(III) complex with long-lived triplet excited states as triplet photosensitizers for triplet–triplet annihilation upconversion. DALTON TRANSACTIONS, 42 (18): (6478-6488). [PMID:23471114] [10.1039/C3DT32815E]
28. Shaozhong Zeng, Limin Guo, Fangming Cui, Zhe Gao, Jian Zhou, Jianlin Shi. (2010) In situ Self-Assembly of Zigzag Polyimide Chains to Crystalline Branched Supramolecular Structures with High Surface Area. MACROMOLECULAR CHEMISTRY AND PHYSICS, 211 (6): (698-705). [10.1002/macp.200900506]

溶液计算器

摩尔浓度计算器

计算溶液所需的质量、体积或浓度。

质量

=

浓度

x

体积

x

分子量

g/mol

稀释计算器

计算配制储备溶液所需的稀释度。

浓度1（C1）

x

体积 1 (V1)

=

浓度 2 (C2)

x

体积 2 (V2)

复溶计算器

复溶计算器允许您快速计算试剂的体积，以复溶小瓶。只需输入试剂的质量和目标浓度，计算器将确定其余部分。

体积（添加到小瓶中）

=

质量（小瓶）

÷

所需的复溶浓度

货号 (SKU)	包装规格	是否现货
N107577-1g	1g	现货
N107577-5g	5g	现货
N107577-25g	25g	现货
N107577-100g	100g	现货
N107577-500g	500g	现货
