数显式邵氏橡胶硬度计是一种先进的一体化数显式硬度测量仪器,该硬度计集测量装置和处理于一体,具有结构紧凑、测值准确、携带方便、造型美观、重量轻和易于操作等优点.
● 具有最大值的锁存、平均值自动计算及欠压报警功能
● 与本机携带的通讯电缆连接,能与计算机进行数据通讯
● 具有自动关闭功能
● 与邵氏硬度测试台连接后能进行更高精度的测量
● 选构件:硬度计测试架
● 电子型号:LR44纽扣电池,1.5V,1颗
● D2479-01为数显邵氏A型橡胶硬度计.它适用于塑料(如薄膜、医疗器具等)、合成橡胶(如密封件、轮胎、胶管/带、电线电缆减振器等)及其它相关化工制品的硬度测量
● D2479-02为数显邵氏D型橡胶硬度计.它适用于硬塑料(如热塑性塑料、硬树脂、尼龙和有机玻璃等)、硬橡胶及其它相关化工制品(如防腐材料、阻燃材料、油漆涂料等)的硬度测量
● D2479-03为邵氏C型数显微孔材料硬度计,是测定压缩率为50%时应力为0.5/cm2以上的含有发泡剂制成的橡塑微孔材料硬度
● A型(D2479-01)和D型(D2479-02)硬度计都是压针,C型硬度计(D2479-03)是弧形的球体状压头

规格和参数

货号	品名	测量范围	测量误差	分辨率	重量	包装
D2479-03-1EA	数显式邵氏C型橡胶硬度计	0HC～100HC	在20HC～90HC内, 误差≤±1HC	0.5HC	233g	1台
D2479-02-1EA	数显式邵氏D型橡胶硬度计	0HD～100HD	在20HD～90HD内, 误差≤±1HD	0.5HD	233g	1台
D2479-01-1EA	数显式邵氏A型橡胶硬度计	0HA～100HA	在20HA～90HA内,误差≤±1HA	0.5HA	233g	1台

技术文档

📋 安全数据表 (SDS)

全面的危险、操作、储存及法规合规文件。

下载 SDS →

✅ 分析证书 (COA)

批次质量数据。输入批号以获取对应 COA。

查询 COA →

📊 产品数据表

产品规格和应用的快速参考摘要。

查看数据表 →

🔬 规格说明书

该级别的完整质量属性和验收标准。

查看规格说明 →

高级数据

一般描述

规格和参数

货号	品名	测量范围	测量误差	分辨率	重量	包装
D2479-03-1EA	数显式邵氏C型橡胶硬度计	0HC～100HC	在20HC～90HC内, 误差≤±1HC	0.5HC	233g	1台
D2479-02-1EA	数显式邵氏D型橡胶硬度计	0HD～100HD	在20HD～90HD内, 误差≤±1HD	0.5HD	233g	1台
D2479-01-1EA	数显式邵氏A型橡胶硬度计	0HA～100HA	在20HA～90HA内,误差≤±1HA	0.5HA	233g	1台

Digital Shore Hardness Tester features integrating measurement device and process.It is compact structure,accurate measurement,easy taking,gracefully shaped,light weight,and easy operation.
● Maximum latch,average value automatic calculation,and Lack-voltage alarm
● Can use data communication after connecting with communication cable
● AUTO OFF
● Process higher accuracy test after linking with Hardness Test Stand
● Standard Accessories:Operation manual,LR44 button cell,5V Power Adapters,Cable and software for RS232C
● Optional Accessory:Hardness Test Stand
● D2479-01 applies for measuring the penetration hardness of rubber,elastomers and other rubber like substances such as neoprene,tyre,and electric wire.It can also be used for similar materials
● D2479-02 is designed for measuring the penetration hardness of duroplasts,such as thermoplastic plastics,animi resin,nylon and organic glass
● D2479-03 is designed for measuring the penetration hardness of Microporous Materials,such as Rubber which has vesicant and stress is 0.5/cm2 when compressibility is 50%

Specifications and parameters

Item No.	Measurment range	Deviation	Resolution	Weight	Package
D2479-03-1EA	0HC～100HC	≤±1HC(20HC～90HC)	0.1HC	233g	1 set
D2479-02-1EA	0HD～100HD	≤±1HD(20HD～90HD)	0.1HD	233g	1 set
D2479-01-1EA	0HA～100HA	≤±1HA(20HA～90HA)	0.1HA	233g	1 set
