FEP管是由聚全氟乙丙烯树脂加入(或不加入)添加剂经挤出成型,主要用于各种频率下电气元件、仪表、电线、电缆绝缘护套、传感器造纸业和纺织业滚筒的表面膜包敷和电气端线绝缘及各种工况条件恶劣的场所的爆、防腐、防粘.具有受热收缩的特性和优异的耐高、低温，耐化学腐蚀、高绝缘和不粘性.
● 材质:氟化乙烯丙烯共聚物(FEP)
● 颜色:透明
● 收缩率:25%-30%
● 具有优异的耐高低温
● 耐化学腐蚀性
● 绝缘性和不粘性

规格和参数

货号	品名	内径×厚度	可包覆直径	包装
F6241-7.9mm-1m	FEP热缩管	7.9×0.2mm	7.9-6.0mm	1m
F6241-14.5mm-1m	FEP热缩管	14.5×0.3mm	14.5-10.0mm	1m
F6241-23.5mm-1m	FEP热缩管	23.5×0.5mm	23.5-20.0mm	1m
F6241-16.5mm-1m	FEP热缩管	16.5×0.4mm	16.5-14.0mm	1m
F6241-10.6mm-1m	FEP热缩管	10.6×0.3mm	10.6-7.3mm	1m
F6241-21.5mm-1m	FEP热缩管	21.5×0.5mm	21.5-17.0mm	1m
F6241-27.0mm-1m	FEP热缩管	27.0×0.5mm	27.0-22.0mm	1m
F6241-4.5mm-1m	FEP热缩管	4.5×0.2mm	4.5-3.3mm	1m
F6241-7.0mm-1m	FEP热缩管	7.0×0.2mm	7.0-5.0mm	1m
F6241-18.0mm-1m	FEP热缩管	18.0×0.5mm	18.0-15.5mm	1m
F6241-5.5mm-1m	FEP热缩管	5.5×0.2mm	5.5-4.3mm	1m
F6241-15.0mm-1m	FEP热缩管	15.0×0.4mm	15.0-12.0mm	1m
F6241-12.5mm-1m	FEP热缩管	12.5×0.3mm	12.5-9.0mm	1m

技术文档

📋 安全数据表 (SDS)

全面的危险、操作、储存及法规合规文件。

下载 SDS →

✅ 分析证书 (COA)

批次质量数据。输入批号以获取对应 COA。

查询 COA →

📊 产品数据表

产品规格和应用的快速参考摘要。

查看数据表 →

🔬 规格说明书

该级别的完整质量属性和验收标准。

查看规格说明 →

高级数据

一般描述

规格和参数

货号	品名	内径×厚度	可包覆直径	包装
F6241-7.9mm-1m	FEP热缩管	7.9×0.2mm	7.9-6.0mm	1m
F6241-14.5mm-1m	FEP热缩管	14.5×0.3mm	14.5-10.0mm	1m
F6241-23.5mm-1m	FEP热缩管	23.5×0.5mm	23.5-20.0mm	1m
F6241-16.5mm-1m	FEP热缩管	16.5×0.4mm	16.5-14.0mm	1m
F6241-10.6mm-1m	FEP热缩管	10.6×0.3mm	10.6-7.3mm	1m
F6241-21.5mm-1m	FEP热缩管	21.5×0.5mm	21.5-17.0mm	1m
F6241-27.0mm-1m	FEP热缩管	27.0×0.5mm	27.0-22.0mm	1m
F6241-4.5mm-1m	FEP热缩管	4.5×0.2mm	4.5-3.3mm	1m
F6241-7.0mm-1m	FEP热缩管	7.0×0.2mm	7.0-5.0mm	1m
F6241-18.0mm-1m	FEP热缩管	18.0×0.5mm	18.0-15.5mm	1m
F6241-5.5mm-1m	FEP热缩管	5.5×0.2mm	5.5-4.3mm	1m
F6241-15.0mm-1m	FEP热缩管	15.0×0.4mm	15.0-12.0mm	1m
F6241-12.5mm-1m	FEP热缩管	12.5×0.3mm	12.5-9.0mm	1m

FEP tube is made of FEP resin is added (or not added) additive by the extrusion,mainly used for the surface at various frequencies of electrical components,instrumentation,wire and cable insulation jacket,sensor paper and textile rollers membrane cladding and electrical wire insulation and a variety of side conditions harsh conditions of places of explosion,corrosion,release.characteristic having heat shrinkage and excellent resistance to high temperature,chemical resistance,high insulation and non-sticky.
● Material:Fluorinated Ethylene Propylene(FEP)
● Color:Clear
● Shrinkage:25%-30%
● high or low temperature resistance
● chemical corrosion resistance
● insulating and non-stick

Specifications and parameters

TITLE	I.D.×Thickness	Coated Diameter	Package
F6241-7.9mm-1m	7.9×0.2mm	7.9-6.0mm	1m
F6241-14.5mm-1m	14.5×0.3mm	14.5-10.0mm	1m
F6241-23.5mm-1m	23.5×0.5mm	23.5-20.0mm	1m
F6241-16.5mm-1m	16.5×0.4mm	16.5-14.0mm	1m
F6241-10.6mm-1m	10.6×0.3mm	10.6-7.3mm	1m
F6241-21.5mm-1m	21.5×0.5mm	21.5-17.0mm	1m
F6241-27.0mm-1m	27.0×0.5mm	27.0-22.0mm	1m
F6241-4.5mm-1m	4.5×0.2mm	4.5-3.3mm	1m
F6241-7.0mm-1m	7.0×0.2mm	7.0-5.0mm	1m
F6241-18.0mm-1m	18.0×0.5mm	18.0-15.5mm	1m
F6241-5.5mm-1m	5.5×0.2mm	5.5-4.3mm	1m
F6241-15.0mm-1m	15.0×0.4mm	15.0-12.0mm	1m
F6241-12.5mm-1m	12.5×0.3mm	12.5-9.0mm	1m
