EC-17 disodium salt

CAS: 910661-33-5 货号: E646854 分子式: C42H34N10Na2O10S 分子量: 916.82 PubChem CID: 167994876
有货
级别和纯度: ≥96%
别名
EC-17 二钠盐
储存条件
避光,-20°C储存,干燥
运输条件
超低温运输
★
规格
库存
价格
数量
5mg
E646854-5mg
期货 Stock Image
¥8,500.90
10mg
E646854-10mg
期货 Stock Image
¥14,500.90
25mg
E646854-25mg
期货 Stock Image
¥28,500.90
50mg
E646854-50mg
期货 Stock Image
¥45,500.90
请输入您要添加的产品数量

概述


EC-17 (disodium salt) is a folate receptor alpha (FRα) targeting contrast agent with fluorescent properties in the visible light spectrum. The peak excitation and emission wavelengths of EC-17 are 470/520 nm.

In Vitro

EC-17 contains the fluorescein fluorochrome and has a spectral wavelength of 490-530?nm. EC-17 is synthesized by a folate (vitamin B9) and fluorescein isothiocyanate (FITC) conjugated through an ethylenediamine spacer to produce folate-FITC, with a molecular weight of 917?kDa. FITC is a derivative of fluorescein functionalized with an isothiocyanate reactive group. The folate-FITC conjugate forms a negatively charged fluorescent molecule that specifically targets cell-surface FRα and is subsequently internalized into the cytoplasm. The signal-to-background ratio (SBR) of EC-17 for HeLa cells range from 0.97 to 7.32 depending on the molarity and concentration of cancer cells. MCE has not independently confirmed the accuracy of these methods. They are for reference only.

In Vivo

The mean fluorescence signal from the animals injected with EC-17 to be 42,234 ± 12,234?au . Fluorescence microscopy for folate-FITC shows a strong signal in all malignant tumors with FR-α expression and no signal in FR-α–negative malignant or benign lesions. MCE has not independently confirmed the accuracy of these methods. They are for reference only.

Form:Solid

IC50& Target:Folate receptor alpha

规格

别名
EC-17 二钠盐
规格或纯度
≥96%
英文名称
EC-17 disodium salt
生化机理
EC-17(二钠盐)是一种叶酸受体α(FRα)靶向造影剂,在可见光光谱中具有荧光特性。EC-17 的激发和发射峰值波长为 470/520u2009nm。
储存条件
避光,-20°C储存,干燥
运输条件
超低温运输
纯度
≥96%
名称和识别符
分子类型
小分子
InChI
1S/C42H42N10O10S.Na.H2/c43-40-51-35-34(37(57)52-40)48-23(19-47-35)18-46-21-3-1-20(2-4-21)36(56)50-30(38(58)59)11-12-33(55)44-13-14-45-41(63)49-22-5-8-27-26(15-22)39(60)62-42(27)28-9-6-24(53)16-31(28)61-32-17-25(54)7-10-29(32)42;;/h1-10,15-17,23,30,34-35,46-48,53-54H,11-14,18-19H2,(H,44,55)(H,50,56)(H,58,59)(H2,45,49,63)(H3,43,51,52,57);;1H/t23?,30-,34?,35?;;/m0../s1
InChIKey
JQYYDKMXXFQNDP-OSYSSLFZSA-N
SMILES
[HH].C1C(NC2C(N1)N=C(NC2=O)N)CNC3=CC=C(C=C3)C(=O)NC(CCC(=O)NCCNC(=S)NC4=CC5=C(C=C4)C6(C7=C(C=C(C=C7)O)OC8=C6C=CC(=C8)O)OC5=O)C(=O)O.[Na]
PubChem CID
分子量
916.82

高级数据

三维结构
交互式化学结构模型





化学和物理性质
溶解性
DMSO : 40 mg/mL (43.63 mM; Need ultrasonic) H2O : <0.1 mg/mL (ultrasonic;warming;heat to 60°C) (insoluble)
质检证书(CoA,COO,BSE/TSE 和分析图谱)
C of A & Other Certificates(BSE/TSE, COO):
输入批号以搜索分析图谱:
溶液计算器

常见问题

本产品的纯度是多少?
本产品的化学纯度(含量)为 ≥96%。批次的具体数值以分析证书(COA)为准。
本产品应如何储存?
请于?20 °C、避光、干燥条件下保存。请与干燥剂一同密封保存,本品对湿气敏感。
本产品如何运输?
本产品采用保温箱配冰袋运输。收货后请立即拆包,并按上述储存条件保存。
本产品的 CAS 号、分子式和分子量是多少?
本产品的 CAS 号为 910661-33-5,分子式为 C42H34N10Na2O10S,分子量为 916.82 g/mol。InChIKey JQYYDKMXXFQNDP-OSYSSLFZSA-N。
如何获取批次专用COA?
每个订单都会随附分析证书(COA),您也可以从账户订单历史中下载。如需订购前的COA,请联系您的客户代表,或使用PDP上的"申请COA"按钮——我们将提供代表性批次的COA。
