Gel-IMAC预装柱是专为实验室抗体快速、简单分离纯化而设计的亲和柱,其原理是利用蛋白质的组氨酸、半胱氨酸和色氨酸的侧链与多种过渡金属离子如Cu2+，Zn2+，Ni2+，Co2+的相互作用,从而达到分离纯化的目的.柱管采用生物耐受性的聚丙烯材料,具有无毒、不与生物分子结合及低溶解度的优点.预装柱的1/16英寸接口,可随实验条件不同与注射器、蠕动泵或色谱系统配套使用.
● 材质:塑料(柱管)
● 基材类型是6%交联琼脂糖
● 有1ml和5ml两种规格
● 具有良好的稳定性、生物相容性和溶剂相容性
● 广泛用于生物制药和生物工程下游蛋白质、核酸及多肽的分离纯化

规格和参数

TITLE	容积	柱管材质	粒径	柱载量	包装
G5293-01-1EA	1ml	塑料	90μm	≥30 umolNi2+/ml	1个
G5293-02-1EA	5ml	塑料	90μm	≥30 umolNi2+/ml	1个

技术文档

📋 安全数据表 (SDS)

全面的危险、操作、储存及法规合规文件。

下载 SDS →

✅ 分析证书 (COA)

批次质量数据。输入批号以获取对应 COA。

查询 COA →

📊 产品数据表

产品规格和应用的快速参考摘要。

查看数据表 →

🔬 规格说明书

该级别的完整质量属性和验收标准。

查看规格说明 →

高级数据

一般描述

规格和参数

TITLE	容积	柱管材质	粒径	柱载量	包装
G5293-01-1EA	1ml	塑料	90μm	≥30 umolNi2+/ml	1个
G5293-02-1EA	5ml	塑料	90μm	≥30 umolNi2+/ml	1个

Ge-IMAC prepacked columns are designed for laboratory antibody is rapid,simple purification.It is based on the specific interaction between certain amino acid side chains exposed on the surface of proteins (mainly His and to a lesser extent Cys and Trp) and transition metal ions,most often Zn²⁺,Ni²⁺,Cu²⁺ or Co²⁺,so as to achieve the purpose of separation and purification.The column using biological resistance of polypropylene material,non-toxic,not combined with biological molecules,and the advantages of low solubility.
● Material:Plastic(column tube)
● Substrate type is 6% cross-linked agarose
● 1ml and 5ml two specifications
● With large adsorption capacity high selectivity,high resolution,easy regeneration and low cost advantages
● Widely used in separation and purification of bio-pharmaceutical and bio-engineering downstream proteins, nucleic acids and peptides

Specifications and parameters

TITLE	Capacity	Column Material	Particle size	DBC
G5293-01-1EA	0.03 oz.(1ml)	Plastic	90μm	≥30 umolNi2+/ml
G5293-02-1EA	0.17 oz.(5ml)	Plastic	90μm	≥30 umolNi2+/ml
