储存缓冲液： 1×PBS, 20% (v/v) Ethanol
本产品可用于从任何表达系统包括杆状病毒、哺乳动物细胞、酵母和细菌中纯化Strep-tag II和Twin Strep-tag II蛋白。Strep-tag II是一个由8个氨基酸（Trp-Ser-His-Pro-Gln-Phe-Glu-Lys）构成的短序列，对重组蛋白的影响可以忽略不计，因此无需去除该tag。进一步改进的Twin Strep-tag II是一个顺序排列的两个Strep-tag II序列（通过内部氨基酸连接），该标签能够像Strep-tag II一样进行温和、快速的纯化。Streptavidin ST是最稳定的蛋白之一，其偶联至高度交联的4%琼脂糖微球上，使得融合蛋白在生理条件下亲和纯化，保证了蛋白质的生物活性。
阿拉丁Strep-tag II 亲和层析介质储存在含20%乙醇的1×PBS中，凝胶和保护液的体积比为1:1，我司产品规格为实际凝胶的体积。
参数
| 指标
|
基质
| 高度交联的4%琼脂糖微球
|
配基
| Streptavidin ST
|
粒径范围
| 45~165 μm |
载量
| 3-5mg Twin Strep-tag II蛋白/mL介质
|
最大流速
| 300 cm/h |
储存
| 含20%乙醇的1×PBS，2~8℃
|
保质期
| 2年 |
使用说明
1、缓冲液的准备
所用水和缓冲液在使用之前建议用0.22μm或0.45μm滤膜过滤。
平衡/洗杂液：100mM Tris-HCl，150mM NaCl，1mM EDTA，pH8.0
或PBS：20mM sodium phosphate，280mM NaCl，6mM potassium chloride，pH7.4
洗脱液：平衡液中加入2.5mM脱硫生物素
再生液：平衡液中加入1mM HABA
注：当样品中存在游离生物素时，需透析后实验，避免影响填料二次使用。
2、样品准备
样品在上样前建议离心或用0.22μm或0.45μm滤膜过滤，减少杂质，提高蛋白纯化效率和防止堵塞柱子。
3、Strep II 亲和层析介质装填
3.1 重力柱的装填
(1) 取合适规格的重力层析柱，装入下垫片，加入适量纯水润洗柱管和垫片，关闭下出口。
(2) 将Strep II 亲和层析介质混合均匀，用枪头吸取适量浆液加入至重力柱中（介质实际体积占悬液的一半），打开下出口流干保护液。
(3) 加入适量纯水冲洗介质，待柱管中液体重力流干后，关闭下出口。
(4) 装入润洗后的上垫片，确保垫片与填料之前没有空隙，且保持水平。
(5) 装填好的重力柱可以直接加入平衡液进行平衡，暂不使用时则加入保护液，2-8℃保存。
3.2 中压层析柱的装填
Strep II 亲和层析介质被广泛应用于工业纯化，因此，涉及到各种中压色谱层析柱的填装，下面介绍填装层析柱的方法。 装柱前根据层析柱直径计算柱子底面积，根据所需装柱高度计算所需介质体积，公式如下：
V = 1.15 × π × r² × h
V：所需介质体积，ml
1.15：压缩系数
r：柱管半径，cm
h：装填高度，cm
注意：所取悬液体积应为介质体积的两倍，因为介质体积只占悬液总体积的一半，另一半为保护液。
(1) 用去离子水冲洗层析柱底筛板与接头，确保柱底筛板上无气泡，关闭柱底出口，并在柱底部留出1-2cm的去离子水。
(2) 将介质悬浮起来，小心的将浆液连续地倒入层析柱中。用玻璃棒沿着柱壁倒入浆液可减少气泡的产生。
(3) 如果使用储液器，应立即在层析柱和储液器中加满水，将进样分配器放置于浆液表面，连接至泵上，避免在分配器或进样管中产生气泡。
(4) 打开层析柱底部出口，开启泵，使其在设定的流速下进行。最初应让缓冲液缓慢流过层析柱，然后缓慢增加至最终流速，这样可避免液压对所形成柱床的冲击，也可以避免柱床形成的不均匀。如果达不到推荐的压力或流速，可以用你所使用泵的最大流速，这样也可以得到一个很好的装填效果。（注意：在随后的色谱程序中，不要超过最大装柱流速的75%）当柱床高度稳定后，在最后的装柱流速下至少再上3倍柱床体积的去离子水。标上柱床高度。
(5) 关闭泵，关闭层析柱出口。
(6) 如果使用储液器，去除储液器，将分配器置于层析柱中。
(7) 将分配器推向柱子至标记的柱床高度处。允许装柱液进入分配器，锁紧分配器接头。
(8) 将装填好的层析柱连接至泵或色谱系统中，开始平衡。如果需要可以重新调整分配器。
4、样品纯化
4.1 孵育法纯化
(1) 根据纯化样品量，取适量Strep II 亲和层析介质加入离心管中，1000rpm离心1min，吸弃上清；也可加入重力柱中，流干保护液。
(2) 向离心管中加入5倍介质体积的平衡液清洗介质，1000rpm离心1min，吸弃上清；如使用重力柱，则直接在重力柱中清洗，直接重 力流干平衡液；重复两次以上。
(3) 加入样品，封闭离心管或重力柱管，4℃振荡孵育2-4h或者37℃孵育30min-2h。
(4) 孵育结束后，1000rpm离心1min，吸弃上清，或过滤收集介质，上清保留作为流穿，用于电泳鉴定。
(5) 用5倍介质体积的洗杂液清洗介质，1000rpm离心1min或重力柱管过滤，去除上清（注意不要吸到介质），重复3-5次，中间建议更换新离心管。
(6) 加入3-5倍柱体积的洗脱液进行洗脱，室温孵育5min，1000rpm离心1min或重力柱管收集洗脱液，可重复2-3次。
4.2 重力柱法纯化
(1) 将装填好的Strep II 亲和层析介质重力柱用5倍柱体积平衡液平衡，使填料处于与目的蛋白相同的缓冲液体系下，重复2-3次。
(2) 将样品加到平衡好的重力柱中，样品保留时间至少2min，保证样品和介质充分接触，收集流出液，可以反复上样增加结合效率。
(3) 用10-15倍柱体积的洗杂液进行洗杂，去除非特异性吸附的杂蛋白，收集洗杂液。
(4) 使用5-10倍柱体积的洗脱液洗脱，分段收集，每一个柱体积收集一管，分别检测，既可以保证所有结合的目的蛋白被洗脱，又可以得到高纯度和高浓度的蛋白。
4.3 中压层析柱法纯化
Strep II 亲和层析介质装填好后，可以用各种常规的中低压色谱系统。
(1) 将泵管道中注满去离子水。去掉上塞子，将层析柱连接至色谱系统中，打开下出口，将预装柱接到色谱系统中，并旋紧。
(2) 用3-5倍柱体积的去离子水冲洗出储存缓冲液。
(3) 使用至少5倍柱床体积的平衡液平衡色谱柱。
(4) 利用泵或样品环上样。注：样品的粘度增加使得即使上样体积很少，也会导致层析柱很大的反压。上样量不要超过柱子的结合能力。大量的样品体积也可能造成很大的反压，使得进样器更难使用。
(5) 用洗杂液冲洗柱子，直到紫外吸收达到一个稳定的基线（一般至少10-15个柱体积）。
(6) 使用5-10倍柱体积的洗脱液洗脱，收集洗脱液，即目的蛋白组分。 介质洗脱结束后，用平衡液冲洗5-10柱体积，然后用纯水冲洗5-10个柱体积，再用20%乙醇冲洗2个柱体积，置于2-8℃保存。
5、SDS-PAGE 检测
将使用纯化产品得到的样品（包括流出组分、洗杂组分和洗脱组分）以及原始样品使用SDS-PAGE检测纯化效果。
6、填料再生和清洗
再生：用5倍柱体积（CV）的去离子水清洗，用15倍柱体积的含1mM HABA的平衡液再生，然后用30倍柱体积的平衡液清洗。脱硫生物素被黄色溶液HABA取代，后者一旦与Streptavidin ST复合即变为红色。HABA随后被平衡液除去，柱子可被重新使用。
保存：填料再生清洗后保存在等体积的保护液中，置于2-8℃保存，防止填料被细菌污染。
This product can be used for the purification of Strep-tag II and Twin Strep-tag fusion proteins from any expression system, including baculovirus, mammalian cells, yeast, and bacteria. Strep-tag II is a short sequence of 8 amino acids (Trp-Ser-His-Pro-Gln-Phe-Glu-Lys) that has a negligible impact on the recombinant protein, making tag removal unnecessary. The further improved Twin Strep-tag consists of two sequentially arranged Strep-tag II sequences (connected by a linker), enabling gentle and rapid purification just like the Strep-tag II. Streptavidin ST is one of the most stable proteins. Its conjugation to highly cross-linked 4% agarose microspheres allows for the affinity purification of fusion proteins under physiological conditions, ensuring protein bioactivity.
Aladdin Strep II Agarose Resin is stored in 1× PBS containing 20% ethanol, with a settled gel to storage solution ratio of 1:1. The product specification refers to the actual volume of the settled gel.
Parameter
| Value / Description
|
Matrix
| Highly cross-linked 4% agarose microspheres
|
Ligand
| Streptavidin ST
|
Particle Size Range
| 45~165 μm |
Binding Capacity
| 3–5 mg Twin-Strep-tag protein/mL resin
|
| Maximum Flow Rate | 300 cm/h |
Storage Conditions
| 1× PBS with 20% ethanol, 2–8°C
|
Shelf Life
| 2 years |
Protocol
1. Buffer Preparation
Water and buffers should be filtered through a 0.22 μm or 0.45 μm membrane before use.
Equilibration/Wash Buffer: 100 mM Tris-HCl, 150 mM NaCl, 1 mM EDTA, pH 8.0
or PBS: 20 mM sodium phosphate, 280 mM NaCl, 6 mM potassium chloride, pH 7.4
Elution Buffer: Equilibration buffer supplemented with 2.5 mM desthiobiotin
Regeneration Buffer: Equilibration buffer supplemented with 1 mM HABA (2-(4-hydroxyphenylazo)benzoic acid)
Note: If free biotin is present in the sample, dialyze prior to use to avoid affecting resin reusability.
2. Sample Preparation
Clarify samples by centrifugation or filtration (0.22/0.45 μm) before loading to reduce impurities, improve efficiency, and prevent column clogging.
3. Column Packing
3.1 Gravity Column Packing
(1) Select a suitable gravity column. Insert the bottom frit, rinse with purified water, and close the outlet.
(2) Resuspend the resin thoroughly. Transfer an appropriate volume of slurry to the column (settled resin volume is half of the slurry). Open the outlet to drain the storage solution.
(3) Rinse with purified water. Close the outlet after draining.
(4) Insert the top frit, ensuring no gaps and a horizontal position.
(5) Equilibrate with equilibration buffer or store with storage solution at 2–8°C.
3.2 Medium-Pressure Column Packing
For industrial-scale purification, medium-pressure columns are often used. Calculate the required resin volume using:
V = 1.15 × π × r² × h
V: Resin volume (mL)
1.15: Compression factor
r: Column radius (cm)
h: Packing height (cm)
Note: The slurry volume should be twice the settled resin volume.
(1) Rinse the column bottom frit and adapter with deionized water. Ensure no bubbles are trapped. Close the outlet and retain 1–2 cm of water.
(2) Resuspend the resin and pour the slurry continuously into the column along the wall to minimize bubbles.
(3) If using a reservoir, fill it with water immediately. Place the distributor on the slurry surface and connect to the pump, avoiding bubbles.
(4) Open the outlet and start the pump at a low flow rate, gradually increasing to the final packing flow rate. Avoid disturbing the bed. Use the pump’s maximum flow rate if needed. After stabilization, flush with 3 CV deionized water. Mark the bed height.
(5) Stop the pump and close the outlet.
(6) Remove the reservoir and place the distributor inside the column.
(7) Lower the distributor to the marked bed height. Allow buffer to enter the distributor and tighten the adapter.
(8) Connect the column to the pump or chromatography system for equilibration. Adjust the distributor if needed.
4. Sample Purification
4.1 Batch Purification
(1) Transfer resin to a centrifuge tube. Centrifuge at 1,000 rpm for 1 min and discard supernatant.
(2) Wash with 5 resin volumes of equilibration buffer. Repeat twice.
(3) Add sample. Incubate at 4°C with shaking for 2–4 h or at 37°C for 30 min–2 h.
(4) Centrifuge at 1,000 rpm for 1 min. Collect supernatant as flow-through for analysis.
(5) Wash with 5 resin volumes of wash buffer. Repeat 3–5 times. Change tubes if needed.
(6) Elute with 3–5 resin volumes of elution buffer. Incubate at RT for 5 min. Collect eluate. Repeat 2–3 times.
4.2 Gravity Column Purification
(1) Equilibrate the column with 5 CV of equilibration buffer. Repeat 2–3 times.
(2) Load sample. Allow at least 2 min residence time. Collect flow-through. Reload to enhance binding.
(3) Wash with 10–15 CV of wash buffer. Collect wash fractions.
(4) Elute with 5–10 CV of elution buffer. Collect fractions (1 CV per tube) for analysis.
4.3 Medium-Pressure Column Purification
(1) Prime the pump with deionized water. Connect the column to the system and tighten.
(2) Flush with 3–5 CV deionized water to remove storage buffer.
(3) Equilibrate with at least 5 CV of equilibration buffer.
(4) Load sample via pump or sample loop. Note: High viscosity increases backpressure. Do not exceed the binding capacity.
(5) Wash with wash buffer until UV absorption stabilizes (typically 10–15 CV).
(6) Elute with 5–10 CV of elution buffer. Collect eluate containing the target protein. After elution, wash with 5–10 CV equilibration buffer, 5–10 CV water, and 2 CV 20% ethanol. Store at 2–8°C.
5. SDS-PAGE Analysis
Analyze samples (flow-through, wash, elution, and crude sample) by SDS-PAGE to evaluate purification efficiency.
6. Resin Regeneration and Cleaning
Regeneration: Wash with 5 CV deionized water. Regenerate with 15 CV regeneration buffer (equilibration buffer + 1 mM HABA), followed by 30 CV equilibration buffer. Desthiobiotin is displaced by HABA, which turns red upon binding to Streptavidin ST. HABA is then removed by equilibration buffer, and the column is ready for reuse.
Storage: After regeneration and cleaning, store the resin in an equal volume of storage solution at 2–8°C to prevent bacterial contamination.
